Send data to Revit model
You are able to send data from the Procurement Module to your Revit model.
Instance/Occurrence Data Attribute configuration
Attributes regarding, Agreement, order and Tender, can be found under “Procurement”. This data can only be sent from dRofus Occurrence to Revit Instance.
![](../../../__attachments/2545713157/image-20230220-163617.png?inst-v=0afdfd47-3bc6-4c62-adaf-adf72ef5899e)
Add Tender Group to Revit family Type
Attributes regardin Tender Group, can be found under “Connections”. This data can be sent from dRofus Item to Revit family type. Only Name can be sent both ways. The rest can only be sent from dRofus to Revit
![](../../../__attachments/2545713157/image-20230220-145335.png?inst-v=0afdfd47-3bc6-4c62-adaf-adf72ef5899e)
Grey letters means that you can only read and send the data and not write data to this parameter
